Peculiarities:
- Fully welded steel structure.
- Easy to operate and maintain.
- High cutting performance, reducing labor costs.
- Maximum workpiece width 2000 mm.
- High carbon steel knives.
- Material feed depth limiter up to 300 mm as standard.
Avoid cutting material that is too thick or has hard beads, slag, line welds, or other defects that are excessively hard.
|
Table depth, mm |
305 |
|
Maximum sheet thickness, mm |
1.25 |
|
Working length, mm |
2000 |
|
Front extensions, mm |
380 |
|
Packaging (LxWxH), mm |
2580x760x1200 |
|
Weight, kg |
511 |
*Max. thickness - indicated for ordinary steel with tensile strength σв, which should not exceed the parameter σв <400 MPa (1 N/mm2 = 1 MPa), not intended for stainless and difficult-to-cut steels.
