PARTICULARITIES:
- It can completely replace pre-hot processing, slow manual flame grinding and arc cutting. Achieve chamfering precision that cannot be achieved with the above-mentioned processing
- Has irreplaceable advantages, especially when beveling the edges of large production parts and materials made of non-ferrous metals or on fixed construction sites
- Can realize convenient chamfering adjustment, easy to operate, economical and reliable. The efficiency is 10-15 times higher than that of economic equipment, which is a development trend in mechanical engineering
TECHNICAL FEATURES:
|
High-voltage |
220 V / 50 Hz |
|
Power consumption |
2 kW |
|
Number of revolutions |
6600 rpm |
|
Max. chamfer`width |
Aluminum-15 mm Plain steel - 12 mm Stainless steel - 8mm |
|
Chamfer angle |
30 ° |
|
Min. sheet thickness |
3 mm |
|
Min. hole diameter |
45 mm |
|
Width of the radius chamfer |
2-8 mm |
|
Overall dimensions (LxBxH) |
600x230x200 mm |
|
Weight (working) |
9 kg |
COMPLET-SET:
|
|
